Basic Info

Model No.: EJH-360

Certification: CE, ISO

Condition: New

Customized: Customized

Alarm Form: Automatically Excluded

Power: 120w

Additional Info

Packaging: paper carton

Productivity: 50pcs/month

Brand: Anhushen

Transportation: Ocean,Land,Air

Place of Origin: China

Supply Ability: 50pcs/month

Certificate: ISO,CE

Port: Shenzhen

Product Description

All Stainless Steel Made Metal Detector for Coal

   EJH-360 is the industrial metal detector in Junhongcompany. On the one hand, the self-studying metal detector has touch screen and user friendly interface whichis easy for handling the machine. On the other hand, its self-studying functionbenefits for eliminating product effect and metal detecting. All in all, the industrial automatic metal detector’s detecting technology has improved comparing with other food metal detector.

Scope of application

 EJH-360 industry metal detector machine is mainly used for detecting the metal chips inside any food, for instance thesea-food, fishery, noodle, frozen food, fruit & dry fruit , sugar, tea,harmaceutical , food additive, condiment, health care products and otherfields. The food industry metal detector is specially good at detecting meat products and aluminum packedproducts.

Product characteristic

1.      all made of Stainlesssteel , anti-erosion and long life span, The frame is easy to install and disassemble,easy for cleaning.

2.      Multi-frequency detecting,self-analysis function, high sensitivity.

3.      With touch screen and userfriendly interface, convenient for operation.

4.      With self-studying function,can analyze and record the up to 100 products.

5.      dual channel detecting:one channel to detect FE and the other to detect non-ferrous metals.

6.      Strong transport drive, ableto convey products under 25kg. speed adjustable. Speed regulator can be added.

7.      Water-Proof, IP65 compliant

8.      Good Anti-interferencefunction: reduce product effect signal form the frozen food and pickled food.

9.      The performance of thebelt conveyer is complied with the American food sanitation standard (FDA), itcan be used for transporting the unpacked food directly.

10.  Can match the pipelineoperation or automatic control device.

11.  Auto-rejection equipmentcan be installed according customer`s requirement.

Technical parameters:

1. Inspection window size:

Normalheight of inspection window (mm): 200

Normalwidth of inspection window (mm): 400

Themeasures of the inspection window can be designed according customersrequirement.

Inspection window size can be customized.

2.      Electrical source: AC110V/220V/380V50/6 0Hz.

3.      Power: 120W

4.      Alarm: Audible and visualalarm, automatic stop

5.      Normal Size (mm): (mm): 1600(L)X 900(W) X800(H)

6.      Gross Weight: approx 380KgsNet Weight: Around 350kgs

---
